GENERAL Power Output:...........................from 0 to 5000W continuously adjustable from front panel. Frequency Range:....................87.5÷108.00 MHz, [ 66÷74 MHz (OIRT), 76÷90 MHz (JPN)] Type of Modulation:...................Direct frequency modulation of carrier, F3E stereo and mono. RF Output Impedance:..............50 ohm. RF Output Connector: ..............7/8” RF Output setting:.....................10W step VSWR: .....................................1.5:1 Max with automatic fold-back VSWR prot. at all phase angles Frequency Stability: ..................Internal TCXO ±2 ppm from -5 to +50°C (better on request) Modulation Capability:...............over ±200 KHz Audio Inputs: ............................L&R analog balanced, Unbalanced composite, SCA, RDS Operator interface setting:.......Encoder Push-Rotary Selector LCD Display:.............................Oled hi-definition graphic type Frequency Control: ..................Synthesizer µprocessor controlled. Programming step:....................10 KHz increments Interface control:........................N°2 RS485 ports RJ45 back panel PC Interface: USB: ...................connector Type B female front panel Telemetry:................................. RJ45 LAN connection with WEB-Server Monitor RF:...............................-10 dBm, BNC-F connector Off Lock RF Muting: .................< -80 dBc. RF Harmonics: .........................Exceeds ETSI/CCIR/FCC requirements (< -75dBc) RF Spurious: ............................Exceeds ETSI/CCIR/FCC requirements ( 3500 mt. Relative Humidity Range: .........0 to 95% non condensing. MONAURAL FEATURES Operational Modes: ..................Mono (L+R) Input Impedance: ......................600 ohm or 10 Kohms balanced. Input Level: ...............................-6 to +12 dBm in 0,5dB step (Other range on request) Input Connector:.......................XLR female - balanced. Audio Frequency Response:.....±0.15 dB, 30 Hz to 15 KHz. Preemphasis setting:.................0, 50µS, 75µS Audio Filter Attenuation:............< -55 dB @ 19 KHz, < -50 dB 20 KHz to 100 KHz T H Distortion + Noise:..............< 0.05% @ 400 Hz FM S/N Ratio:............................better than -80 dB RMS ref. ±75 KHz 50µs deemphasis. MULTIPLEX FEATURES Composite Input Impedance:.....600 ohm or 10 Kohms balanced. Composite Input Level:..............-12 to +6 dBm in 0,5dB step (Other range on request) Input Connector:........................BNC female. AES/EBU Input Connector:........BNC female Composite Response:...............±0.2 dB, 30 Hz to 100 KHz. THDistortion + Noise:................0.05% @ 400 Hz Intermodulation Distortion:.........0.05%, 1 KHz/1.3 KHz, 1:1 ratio FM S/N Ratio:........................... better than -80 dB RMS ref. ±75 KHz 50 µs de-emph. decoded. STEREO CODER FEATURES Audio Input Impedance:.............600 ohm balanced, 15 Kohm unbalanced. Audio Input Level:......................-6 to +6 dBm in 0,5dB step (Other range on request) Input Connector:........................XLR female. Audio Frequency Response:.....±0.15 dB, 30 Hz to 15 KHz. Preemphasis setting:.................0, 50µS, 75µS THDistortion + Noise:.................0.05% @ 400 Hz Intermodulation Distortion:.........0.05%, 1 KHz/1.3 KHz, 1:1 ratio FM S/N Ratio:............................-80 dB RMS at ±75 KHz 50 µs de-emphasis. Pilot Frequency: ........................19 KHz ± 1 Hz 38 KHz Suppression:.................-60 dB (typ. -70 dB) Audio Filter Attenuation:.............< -55 dB @ 19 KHz,
