High performance 4K HEVC H.265 and AVC H.264 Encoder for exceptional 4K Broadcast content contribution and distribution Via Satellite and IPTV - OTT - CDN networks

It integrates encoding in H.265/HEVC and H.264/AVC and multiplexing functions in one standard rack 1U case. It also support four HD-SDI and two HDMI (2.0) channel UHD signal input (hot redundancy) for encoding, and also 2 ASI & 32 IP input for remux.

To enhance the transport capacity, it combines 1 DVB-C/T carriers output with one RF port. It is also equipped with 4 ASI ports to mirror out RF carrier and IP port to output TS in 1* MPTS.



Key Features

 * Support 4 HD-SDI INPUTS 2 HDMI 2.0 (Mux) input and 1 HDMI 2.0 (Loop out) output



 * Support HDCP 2.2 and HDCP 1.4



 * Support 2 ASI & 32 IP input (MPTS/SPTS) over UDP and RTP protocol



 * Support up to 2160P 60Hz RGB/YCbCr 4:4:4 input



 * Support H.265/HEVC and H.264/AVC video encoding(>>Test TS Download)



 * Support video resolution upscale transform (1080P and 4K convert to each other)



 * Support CBR video bitrate mode



 * Support MPEG1 Layer 2, LC –AAC audio encoding



 * Support PID remapping / accurate PCR adjusting / PSI/SI editing and inserting



 * Support IP (1000M/100M) Output 1 MPTS over UDP and RTP; IP null packet filter



 * Support 1 TS output through 4 ASI output ports



 * Real-time output bit-rate monitoring



 * Update device through web based NMS port



 * Support LCD / keyboard operating(optional), and network management (web)



Inputs:

4 HD-SDI input, BNC interface



1×HDMI input (2.0) with 2 HDMI port, HDCP 2.2/1.4



2 ASI input, BNC interface



32 IP input over UDP and RTP protocol



Video Input Resolution



3840×2160_60P,3840×2160_59.94P

3840×2160_50P,3840×2160_30P

3840×2160_29.96P,3840×2160_25P

3840×2160_24P,1920×1080_60P

1920×1080_59.94P

1920×1080_50P

1920×1080_30P

1920×1080_25P

1920×1080_24P



Chroma RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 (2160P_50/60Hz only)



Encoding H.265/HEVC, H.264/AVC Chroma 4:2:2, 4:2:0



Video Bit-rate 1Mbps~23Mbps



Audio MPEG-1 Layer 2, LC-AAC



Sampling rate 48KHz



Bit-rate 64Kbps~256Kbps each channel



Multiplexing 2 ASI input multiplexed with local 1 channel of TS



PID remapping (automatically or manually)

Accurate PCR adjusting

Generate PSI/SI table automatically

Stream output 1 ASI output through 4 BNC interfaces + 1 MPTS over UDP/RTP, 1000M/100M Base-T Ethernet interface (unicast/ multicast)



System function access via web NMS GUI with LCD and Keyboard LCD/keyboard operating, web NMS supporting Ethernet software & hardware upgrade



Miscellaneous



Dimension (W× L× H) 482mm×455mm×44mm



Approx weight 4kg



Temperature 0~45℃(work),  -20~80℃(Storage)



Power AC 100V-220V±10%, 50/60Hz Consumption 25W
